Glass fiber sizing agent
VONDIC
Functional Products
The Bondic series of water-based urethane resins for glass fiber bundling agents are high-molecular-weight thermoplastic urethane resins emulsified and dispersed in water, developed based on DIC's urethane synthesis and emulsification technologies.
• High bundling ability: Simply drying creates a tough film that is effective in suppressing fiber fuzzing.
• Compounding stability: Nonionic, allowing it to be compounded with a variety of materials.
• Various durability characteristics: By optimizing the resin design, we can provide urethane resins that meet a variety of requirements, including resistance to thermal decomposition, thermal discoloration, and solvents.
About Glass fiber sizing agent
DIC's Advantages
Major Applications
• Chopped Strands
Used as a reinforcing material for engineering plastics in automotive and electrical components.
• Roving
It is used as a reinforcing material for various construction materials such as bathtubs, water tanks, and plumbing pipes.
Product Lineup
| Product name | Polyol Type | Ionic | Yellowing | NV % |
Vis mPa・s |
pH | MFT ℃ |
Solvent |
|---|---|---|---|---|---|---|---|---|
| 1310NE | PE | Nonion | ✓ | 49-51 | <1000 | 8.0-10.0 | r.t. | Water |
| 1940NE | PE | Nonion Anionic |
- | 49-51 | <1000 | 7.0-9.0 | r.t. | Water |
| 1970NE | PE | Nonion | - | 44-46 | <1000 | 5.0-8.0 | r.t. | Water |
| 2260NE | PE | Nonion Anionic |
- | 39-41 | <1000 | 6.5-8.5 | r.t. | Water |
| 1640NE | PEs | Nonion | - | 39-41 | 300-1000 | 6.0-8.0 | r.t. | Water |
| 1980NE | PEs | Nonion | - | 44-46 | <1000 | 6.0-8.0 | 40< | Water |
| 2220 | PEs | Nonion | - | 39-41 | <200 | 3.0-6.0 | 40< | Water/NMP |
※PEs：PolyesterpolyesterPE：Polyether
| Product name | Film properties | Discoloration ⊿b 200℃ 30minutes |
Pyrolysis reduction rate % ＠350℃ |
Solubility reduction rate % Acetone/ Styrene |
Application | |||
|---|---|---|---|---|---|---|---|---|
| 100％ Modulus |
Breaking Strength MPa |
Maximum elongation % |
Melting temperature ℃ |
|||||
| 1310NE | 2 | 26 | 500 | 170-180 | 24 | 15 | 7/5 | FRTP |
| 1940NE | 2 | 15 | 750 | 130-145 | 3 | 21 | 11/8 | FRTP |
| 1970NE | 3 | 23 | 540 | 150-170 | 7 | 6 | 4/12 | FRTP |
| 2260NE | 1 | 18 | 660 | 175-180 | 3 | 10 | 9/7 | FRTP |
| 1640NE | 3 | 33 | 450 | 180-190 | 17 | 16 | 18/15 | FRTP/FRP |
| 1980NE | 14 | 14 | 160 | 70-90 | 4 | 6 | 90/100 | FRTP/FRP |
| 2220 | 13 | 20 | 200 | 65-85 | 5 | 10 | 100/70 | FRTP/FRP |
We also have additional model numbers available beyond those listed above. Please contact us for further details.
Please contact our sales staff when making an inquiry about the product to see if the product you want can be imported into your country.
